Novelty - Agathon Mini Fine Centering 7980/1
- Simplified tool concept
- Centering quick change mold inserts
- Installation variants with and without bushing
- Positioning of plates
- Positioning of handling tools
Applications
- Plate centering for precise guidance and maximum load capacity
- Centering systems for mold tool dimensions of 100 mm to 1000 mm edge length
- Use as individual centering of cavities
- Centering of hybrid injection molds
- Guiding ejection plates or plate guide for ventilation stroke
- Tool centering on the injection molding machine
- Tool upgrade (rework): Exchange of conventional guide blocks for round fine centering systems
High initial load capacity and precision
- High initial load capacity at centering start
- Cage retaining and positioning system
- Long centering stroke
- No backlash because the rolling elements are preloaded
- No stick-slip
High design freedom
- The centering units can be placed anywhere on the entire tool surface
- Commonly used number of units is 2 to 4
- The bushes can either be secured with clamps or clamped between the plates via the collar
Cleanroom compatible
- Abrasion free due to rolling off rollers
- Minimum amount of lubrication
- Use for high temperature applications
Ease of use
- Simple calculation scheme for size + number of required centering units
- Free download of CAD data in all formats
- Shape and location holes manufactured in one machining operation
- Several dimensions ready for installation are available from stock
- Customized solutions on request
